ABB A Line Series Contactor, 110 V ac Coil, 3-Pole, 25 A, 4 kW, 3NO, 690 V ac
Technical Document
Specifications
Brand
ABBCoil Voltage
110 V ac
Number of Poles
3
Contact Voltage Rating
690 V ac
Contact Current Rating
25 A
Range
A9
Series
A Line
Power Rating
4 kW
Function
Motor Control
Normal State Configuration
3NO
Number Of Auxiliary Contacts
1
Auxiliary Contact Configuration
1NO
Terminal Type
Screw
Length
74mm
Width
44mm
Depth
74mm
Control Voltage
220 → 240 V ac
Maximum Operating Temperature
+55°C
Load Voltage
600V ac
Minimum Operating Temperature
-40°C
Load Current
25A
Pole and Throw Configuration
3P
Mounting Style
DIN Rail Mount
Product details
A Series AC Controlled Contactors
Three main poles
One N/O auxiliary contact
Front and side mounted auxiliary contact blocks
Location for surge protection
DIN rail and back plate mounting
Manufactured to IEC947-4-1, EN60 047-4-1
CE marked
Approvals
UL, CSA, BV, DNV, GL, LROS, PRS and RINA
Stock information temporarily unavailable.
Please check again later.
26.540 OMR
26.540 OMR Each (ex VAT)
27.867 OMR
27.867 OMR Each (inc. VAT)
1
26.540 OMR
26.540 OMR Each (ex VAT)
27.867 OMR
27.867 OMR Each (inc. VAT)
1
Buy in bulk
| quantity | Unit price |
|---|---|
| 1 - 4 | 26.540 OMR |
| 5 - 9 | 25.660 OMR |
| 10 - 24 | 24.740 OMR |
| 25 - 49 | 23.785 OMR |
| 50+ | 22.785 OMR |
