APEM Toggle Switch, Panel Mount Mount, On-On, SPDT, Solder Terminal, 24 V dc, 220 V ac

RS Stock No.: 236-9244Brand: APEMManufacturers Part No.: 106362103
brand-logo
View all in Toggle Switches

Technical Document

Specifications

Brand

Apem

Contact Configuration

SPDT

Product Type

Toggle Switch

Switch Operation

On-On

Switch Contact Current

3A

Mount Type

Panel Mount

Terminal Type

Solder

Illuminated

No

Actuator Length

11mm

Contact DC Voltage

24V dc

Contact AC Voltage

220V ac

Minimum Operating Temperature

-40°C

Actuator Material

Brass

Maximum Operating Temperature

85°C

Switch Configuration

2P, 1P

Height

38.2mm

Standards/Approvals

RoHS

Series

10600

Country of Origin

France

Product details

Switches series 10600

Range of switches with threaded barrel Ø 10 mm.
Standard lever version.
Terminations sealed with epoxy resin.
