Arcol 50Ω Non-Inductive Resistor 100W ±1% AP101 50R F 50PPM
Technical Document
Specifications
Brand
ArcolResistance
50Ω
Power Rating
100W
Tolerance
±1%
Technology
Non-Inductive
Series
AP101
Package/Case
TO-247
Temperature Coefficient
±50ppm/°C
Lead Pitch
10.42mm
Product details
AP101 Series 100W TO-247 High Power Resistors
The AP101 series non-inductive TO-247 style thick film Power Resistors capable of dissipating 100 watts. The AP101 series benefits from new material technologies and an extremely low thermal resistance.
TO-247 style power package capable of dissipating 100 watts
Extremely low thermal resistance at 0.9°C/W resistor hotspot to metal tab
Thick Film design
Single screw mounting to heat sink
Moulded case for protection
Electrically isolated case
Non-Inductive design
Recommended: The use of thermal grease between metal tab and heat sink
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
5.665 OMR
5.665 OMR Each (ex VAT)
5.948 OMR
5.948 OMR Each (inc. VAT)
Standard
1
5.665 OMR
5.665 OMR Each (ex VAT)
5.948 OMR
5.948 OMR Each (inc. VAT)
Standard
1
Stock information temporarily unavailable.
Please check again later.
| Quantity | Unit price |
|---|---|
| 1 - 9 | 5.665 OMR |
| 10 - 24 | 5.214 OMR |
| 25 - 49 | 4.708 OMR |
| 50 - 99 | 4.186 OMR |
| 100+ | 3.580 OMR |
