JST, EL Male Connector Housing, 4 Way, 1 Row
Technical Document
Specifications
Brand
JSTNumber Of Contacts
4
Number Of Rows
1
Gender
Male
Series
EL
For Use With
4.5 mm Disconnectable Crimp Wire-to-Wire Connector
Length
19.3mm
Housing Material
Nylon
Country of Origin
Japan
Product details
JST EL Connector Housing
The EL range of connector housings from JST have a 4.5mm pitch. The contacts are easily inserted and installed into the connector housings and due to the housings wide surface area, a safe and smooth connection can be maintained when mating, even if mechanical distortion occurs.
Features and Benefits
• 4.5mm pitch
• 2 to 15 circuits
• Natural colour
• Wire to wire configurations and fittings
• Locking lances ensure the contact is correctly installed and locked in
• Highly durable due to slit in housing arm lock mechanism
Standards
Compliant with UL, CSA, TUV
Electrical Appliance and Material Safety Act (spatial / creepage distance for insulating material)
