JST Female Connector Housing, 4 Way, 2 Row
Technical Document
Specifications
Brand
JSTNumber Of Contacts
4
Number Of Rows
2
Gender
Female
Body Orientation
Straight
Country of Origin
Japan
Product details
JST YL Series Receptacle Housings
A range of multi-pole receptacles from the JST YL series of wire-to-wire connectors. The receptacles are intended for use with crimp pin contacts, RS 392-2666. Voltage and current ratings are dependent on wire size used.
• Suitable wire size: 26 to 20 AWG (0.13 to 0.5 mm2)
• Maximum working voltage: 300V
• Maximum current rating: 10A
• UL, CSA, and TUV approvals
4.5mm wire-to-wire JST YL Series
A range of JST YL series 4.5mm pitch wire-to-wire crimp style connectors
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
1.870 OMR
0.187 OMR Each (In a Pack of 10) (ex VAT)
1.964 OMR
0.196 OMR Each (In a Pack of 10) (inc. VAT)
10
1.870 OMR
0.187 OMR Each (In a Pack of 10) (ex VAT)
1.964 OMR
0.196 OMR Each (In a Pack of 10) (inc. VAT)
10
Stock information temporarily unavailable.
Please check again later.
| quantity | Unit price | Per Pack |
|---|---|---|
| 10 - 240 | 0.187 OMR | 1.870 OMR |
| 250 - 990 | 0.143 OMR | 1.430 OMR |
| 1000 - 4990 | 0.138 OMR | 1.375 OMR |
| 5000 - 9990 | 0.138 OMR | 1.375 OMR |
| 10000+ | 0.132 OMR | 1.320 OMR |
