Technical Document
Specifications
Brand
PanasonicCapacitance
0.22F
Voltage
5.5V dc
Mounting Type
Through Hole
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+70°C
Diameter
10.5mm
Height
5mm
Dimensions
10.5 (Dia.) x 11.5mm
Lead Pitch
5mm
Leakage Current
300 μA
Equivalent Series Resistance
≤75Ω
Lifetime
1000h
Series
SD
Tolerance
-20 → +80%
Lead Diameter
1.7 x 0.2mm
Dielectric Material Family
Electrical Double Layer
Terminal Type
Radial
Lead Spacing
5 mm
Product Diameter
10.5mm
Capacitor Family
Electric Double Layer
Country of Origin
Japan
Product details
Wet type electric double layer capacitors (Gold capacitor) (activated charcoal electrodes with organic electrolyte)
Ideal for IC memory back up (μA range load)
No charge/discharge circuitry required unlike batteries and cannot be over or under charged
Charge/discharge cycles greater than 100000 times
Volumetric efficiency (SD is 30% smaller than SG series, SG is 50% smaller then NF series)
Longer life than a secondary battery
Recommended applications include memory back-up for video and audio equipment, printers, cameras, data terminals, telephones, intelligent remote controls and rice cookers
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
143.520 OMR
0.718 OMR Each (In a Bag of 200) (ex VAT)
150.696 OMR
0.754 OMR Each (In a Bag of 200) (inc. VAT)
200
143.520 OMR
0.718 OMR Each (In a Bag of 200) (ex VAT)
150.696 OMR
0.754 OMR Each (In a Bag of 200) (inc. VAT)
Stock information temporarily unavailable.
200
| Quantity | Unit price | Per Bag |
|---|---|---|
| 200 - 800 | 0.718 OMR | 143.520 OMR |
| 1000 - 1800 | 0.682 OMR | 136.344 OMR |
| 2000+ | 0.646 OMR | 129.168 OMR |
